End Cap Master Flash®

For metal roofs

For standing seam roofs

Accommodates all seam heights.

Available in dark gray and black EPDM rubber

Aluminum base

Three styles and sizes available

Call For Quote 800-927-4375

  • Standing seam roof end cap flashing
  • Available in Light Gray, Dark Gray, and BlackEPDM Rubber
  • Applications: Skylights • Metal Curbs • Ridge Applications • Job Site RetrofitBase
  • 3 sizes (Mini, #1, #2)
  • Height Range: ¾” to 3-1/4” (19 to 82mm) Pipes
  • Base:
    Mini 2-3/4” W X 3” L (69mm W X 76mm L)
    #1 4-1/4”
    W  X3” L (107mm W X 76mm L)
    #2 5-3/4” W X 7-1/4” L (146mm W X 184mm L)
  • Allows side wall of the end cap to form on roof panels
  • Base allows application at both terminating points of the sheeting or roofing material
  • The expansion feature accommodates all seam heights. Allows side wall of the end cap to form on roof panels.
[pdf-embedder url=”https://masterflash.aztecwasher.com/wp-content/uploads/2018/10/MASTER-CAP-MINI-MF-PRODUCT-SIZE-COLOR-110518.pdf” title=”MASTER CAP MINI MF PRODUCT SIZE COLOR 110518″]

ADVANCED OZONE RESISTANCE tested to… EPDM 70 hour @ 500 pphm

HIGH-TEMPERATURE RESISTANCE

Tested to

Intermittent +135°C (+275°F)

Continuous +100°C (+212°F)

LOW-TEMPERATURE RESISTANCE tested to… – 55°C (-67°F)

COMPRESSION SET Maximum… 25%
